Start 12 V |
|
10016 |
10020 |
10024 |
10028 |
10030 |
10034 |
15016 |
15024 |
15028 |
15034 |
| 1 |
Q |
Capacity |
KG |
1.000 |
1.000 |
1.000 |
1.000 |
1.000 |
1.000 |
1.500 |
1.500 |
1.500 |
1.500 |
| 2 |
|
Up to |
MM |
1.600 |
2.000 |
2.400 |
2.800 |
2.600 |
2.800 |
1.600 |
2.400 |
2.400 |
2.800 |
| 3 |
|
Residual capacity Up to H3 |
KG |
1.000 |
1.000 |
1.000 |
1.000 |
700 |
700 |
1.500 |
1.500 |
1.000 |
1.000 |
| 4 |
C |
Load center |
MM |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
| 5 |
|
Traction Type (manual or self propelled) |
|
s |
s |
s |
s |
s |
s |
s |
s |
s |
s |
| 6 |
|
Driving position (1)=Walkie-(2)=Ride on |
|
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 7 |
|
Wheelsfull Ruber-Aluminium Cast |
|
No |
No |
No |
No |
No |
No |
No |
No |
No |
No |
| 8 |
|
Wheels(X)=Driving (N. Front/Rear) |
|
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
0/X=1 |
| 9 |
|
Rollers (N. Front/Type) |
|
4 / V |
4 / V |
4 / V |
4 / V |
4 / V |
4 / V |
4 / V |
4 / V |
4 / V |
4 / V |
| 10 |
H3 |
Maximum lifting height standard lift at forks |
MM |
1.600 |
2.000 |
2.400 |
2.800 |
3.000 |
3.400 |
1.600 |
2.400 |
2.800 |
3.400 |
| 11 |
H2 |
Normal free lift |
MM |
1.509 |
1.909 |
178 |
182 |
128 |
160 |
1.509 |
168 |
180 |
200 |
| 12 |
|
Standard forks _ L (lenght) |
MM |
1.120 |
1.120 |
1.120 |
1.120 |
1.120 |
1.120 |
1.120 |
1.120 |
1.120 |
1.120 |
| 13 |
|
_B (width at point) |
MM |
115 |
115 |
115 |
115 |
115 |
115 |
115 |
115 |
115 |
115 |
| 14 |
|
_S (thickness) |
MM |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
| 15 |
L |
Dimensions _ Total lenght |
MM |
1.784 |
1.784 |
1.824 |
1.824 |
1.824 |
1.824 |
1.784 |
1.824 |
1.824 |
1.824 |
| 16 |
L2 |
Lenght without forks |
MM |
664 |
664 |
704 |
704 |
704 |
704 |
674 |
714 |
714 |
714 |
| 17 |
B |
Dimensions _ Total width |
MM |
770 |
770 |
850 |
850 |
850 |
|
770 |
850 |
850 |
1.000 |
| 18 |
M |
External fork width (min/max) |
MM |
520 |
520 |
520 |
520 |
520 |
520 |
548 |
548 |
548 |
548 |
| 19 |
|
External legs width (min/max) |
MM |
490 |
490 |
490 |
490 |
490 |
490 |
490 |
490 |
490 |
490 |
| 20 |
|
Internal legs width (max) |
MM |
290 |
290 |
290 |
290 |
290 |
290 |
290 |
290 |
290 |
290 |
| 21 |
|
Fork clearance from ground |
MM |
91 |
91 |
91 |
91 |
91 |
91 |
91 |
91 |
91 |
91 |
| 22 |
H1 |
Height with lowered mast |
MM |
1.958 |
2.305 |
1.758 |
1.958 |
1.980 |
2.243 |
1.958 |
1.803 |
2.003 |
2.313 |
| 23 |
H4 |
height with lifted mast |
MM |
2.050 |
2.450 |
2.850 |
3.250 |
3.450 |
3.850 |
2.130 |
2.951 |
3.330 |
3.930 |
| 24 |
H6 |
Height of rubber from ground |
MM |
1.400 |
1.400 |
1.400 |
1.400 |
1.400 |
1.400 |
1.400 |
1.400 |
1.400 |
1.400 |
| 25 |
WA |
Turning radius _ External |
MM |
1.400 |
1.400 |
1.445 |
1.445 |
1.445 |
1.445 |
1.445 |
1.445 |
1.445 |
1.550 |
| 26 |
AST |
Minimum Aisle _ Pallets 800X1200 |
MM |
1.860 |
1.860 |
1.910 |
1.910 |
1.910 |
1.910 |
1.870 |
1.930 |
1.930 |
2.030 |
| 27 |
|
_ Pallets 1200X1200 |
MM |
- |
- |
- |
- |
- |
- |
- |
- |
- |
- |
| 28 |
|
Stability CEE norms 86/663-89/240 |
|
yes |
yes |
yes |
yes |
yes |
yes |
yes |
yes |
yes |
yes |
| 29 |
|
Speed _ Driving with/without load |
KM/H |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
2.6/3.6 |
| 30 |
|
Speed _ Lifting with/without load |
M/Min |
3.5/6 |
3.5/6 |
3.5/6 |
3.5/6 |
3.5/6 |
3.5/6 |
2.3/4 |
2.3/4 |
2.3/4 |
2.3/4 |
| 31 |
|
Speed _ Lowering with/without load |
M/Min |
REG |
REG |
REG |
REG |
REG |
REG |
REG |
REG |
REG |
REG |
| 32 |
|
Slopes _ with/without load |
% |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
| 33 |
|
Weight of stracker without batteries |
KG |
328 |
344 |
474 |
486 |
516 |
531 |
408 |
576 |
597 |
622 |
| 34 |
|
Wheels and rollers _ Driving N./Dimensions |
N/MM |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
1/200X75 |
| 35 |
|
_ Front N./Dimensions |
N/MM |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
4/85X56 |
| 36 |
|
_ Rear N./Dimensions |
N/MM |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
2/70X55 |
| 37 |
M2 |
Ground Clearance _ at lowest point |
MM |
32 |
32 |
32 |
32 |
32 |
32 |
32 |
32 |
32 |
32 |
| 38 |
|
Brakes (1)=pedal(2)=Parking- (3)=on rudder |
|
2-3 |
2-3 |
2-3 |
2-3 |
2-3 |
2-3 |
2-3 |
2-3 |
2-3 |
2-3 |
| 39 |
|
(1)=mecc- (2)=Hydraulic- (3)=Electromagnetic |
|
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
| 40 |
|
Electric motors _ Traction motor p S2 |
KW |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
| 41 |
|
Lifting motors _ Traction motor p S3 25% |
KW |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
| 42 |
|
Speed control reverse directions |
|
yes |
yes |
yes |
yes |
yes |
yes |
yes |
yes |
yes |
yes |
| 43 |
|
Type _ (1)=Manual-(2)=Electronic |
|
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 44 |
|
Steering type _ (1)=Mecc- (2)=Hydraulic |
|
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 45 |
|
Transmission _ type (1)=gears |
|
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 46 |
|
Hydraulic system _ Pressure |
Bar |
125 |
125 |
125 |
125 |
125 |
125 |
120 |
120 |
120 |
120 |
